Material | Ductile iron |
Standard | EN545, EN598, ISO2531, ANSI/AWWA, etc |
Size | DN50-DN2600mm |
Color | Blue,Black,Red Ect. |
Joint Type | Flange type |
Pressure | PN10/PN16/PN25/PN40 |
OEM | Acceptable |
Fitting Types | Socket bend, Flanged bend, Socket and Flanged Tee, Flanged socket, Socket taper, blank flanges, as well as Flanged adaptor,coupling, dismantling joints, Fitting for PVC pipes and Other pipeline accessories |
Surface treatment | Fusion bonded epoxy coating |
Cement lining inside and zinc and bitumen coating outside | |
Zinc+bitumen inside and outside | |
According to customers' requirements | |
Inspection | Foundry in-house: Third party inspection available upon request |
Application | Stormwater systems |
Advantage | We can make various high quality ductile iron fittings according to customer's requests. |
Package | Standard wooden pallets or wooden cases |
DN mm | T mm | Flanged Spigots | ||||
L mm | S mm | Mass(kgs) | ||||
PN10 | PN16 | PN25 | ||||
80 | 7 | 350 | 215 | 7.8 | 7.8 | 7.8 |
100 | 7.2 | 360 | 215 | 9.6 | 9.6 | 10.2 |
150 | 7.8 | 380 | 225 | 15.6 | 15.6 | 16.6 |
200 | 8.4 | 400 | 230 | 22.5 | 22.5 | 24.5 |
250 | 9 | 420 | 240 | 32 | 31.5 | 35.5 |
300 | 9.6 | 440 | 250 | 43 | 42.5 | 47.5 |
350 | 10.2 | 460 | 260 | 52 | 55 | 64 |
400 | 10.8 | 480 | 270 | 64 | 70 | 81 |
450 | 11.4 | 500 | 280 | 78.5 | 87.0 | 98.0 |
500 | 12 | 520 | 290 | 94 | 109 | 121 |
600 | 13.2 | 560 | 310 | 133 | 159 | 173 |
700 | 14.4 | 600 | 330 | 179 | 194 | |
800 | 15.6 | 600 | 330 | 226 | 245 | |
900 | 16.8 | 600 | 330 | 272 | 295 | |
1000 | 18 | 600 | 330 | 328 | 369 | |
1100 | 19.2 | 600 | 330 | 394 | 430 | |
1200 | 20.4 | 600 | 330 | 456 | 520 | |
1400 | 22.8 | 710 | 390 | 664 | 732 | |
1500 | 24 | 750 | 410 | 812 | 900 | |
1600 | 25.2 | 780 | 430 | 922 | 1024 | |
1800 | 27.6 | 850 | 470 | 1196 | 1322 | |
2000 | 30 | 920 | 500 | 1534 | 1687 | |
2200 | 32.4 | 990 | 540 | 1948 | 2115 | |
2400 | 34.8 | 1060 | 570 | 2409 | 2611 | |
2600 | 37.2 | 1130 | 610 | 2918 | 3153 | |
Flange Spigot is a type of flange that is designed to be connected to pipes that have spigot ends. It is commonly used in pipe laying applications, particularly in underground water and sewer systems. The spigot end of the pipe is inserted into the flange spigot, which is then fastened securely using bolts or screws. This creates a tight seal that prevents leaks and ensures the integrity of the system.
We specialize in producing high-quality flange spigots that are made from top-grade materials and manufactured to strict industry standards. Our flange spigots are available in a range of sizes and configurations to fit different types of pipes and custom requirements.
One of the key features that sets our flange spigots apart from others in the market is their superior strength and durability. Made from materials such as carbon steel, stainless steel, and ductile iron, they can withstand high pressures and operating temperatures without compromising their integrity. Our flange spigots are also resistant to corrosion, which ensures a longer lifespan and reduces maintenance costs.
In addition to their technical specifications, our flange spigots are also designed with ease of installation in mind. They come with pre-drilled bolt holes and alignment pins that make it easy and quick to attach the spigot to the pipe. This reduces the risk of errors during installation and saves time and effort for our clients.
If you are looking for a reliable and dependable flange spigot supplier, look no further than X Company. Our commitment to quality and customer satisfaction is unparalleled, and we go to great lengths to ensure that each and every flange spigot we produce meets the highest standards of excellence. Contact us today to learn more about our products and services.
